Description
Multi-pitch commercial tracking without DC optimizers.
GoodWe GW25K-ET is a 25 kW commercial three-phase hybrid inverter with 3 independent MPPT trackers and dual 50 A high-voltage battery ports, engineered to optimize complex multi-pitch warehouse roofs and dual-column storage.
3 Independent 30 A MPPT Trackers
Eliminates string mismatch across East, South, and West commercial roof pitches (6 strings total).
Dual 50 A High-Voltage Battery Ports
Connects two separate battery towers directly without external DC combiner boxes (100 A combined).
25 kVA Continuous Three-Phase Backup
Delivers full emergency power to commercial HVAC, ventilation, and machinery during outages.
100% Phase Unbalanced Output
Dynamically diverts power to heavily loaded single-phase circuits to eliminate peak demand charges.
More product details
Sprawling commercial roofs with 3 distinct pitch orientations suffer severe mismatch losses if combined on fewer trackers. The GW25K-ET provides 3 independent 30 A MPPT trackers (Isc 38 A), optimizing power from 6 strings of modern 600W+ bifacial modules.
- 3 MPPT channels allow dedicated tracking for East, South, and West warehouse pitches with zero inter-string clipping.
- Accepts up to 37,500 W of solar generation, routing daytime power directly to building machinery and dual battery banks.
- Wide MPPT window (200–850 V) maintains peak conversion efficiency across extreme summer and winter string voltages.
GoodWe
Compare different models
Scroll sideways to compare every model.
Dual-tower battery integration with 25 kVA emergency power.
Connecting large battery capacity (40–60 kWh) typically requires either dangerously tall single columns or expensive external combiner switchgear. The GW25K-ET features dual independent 50 A battery ports to plug two floor stacks directly into the inverter. Two independent 50 A battery ports deliver up to 50 kW combined DC throughput across a 200–800 V window. 25 kVA continuous three-phase backup sustains commercial workshops and critical facility sub-panels in under 10 ms. 100% phase-unbalanced load balancing shifts power to heavy single-phase tools without pulling grid electricity.
Takes 37500 W PV on three 30 A trackers
Three trackers manage six strings in a 2/2/2 layout with 30 A per MPPT and 38 A short-circuit current. Operating range spans 200 to 850 V.
Holds 25000 VA backup and 30000 VA surge
The backup stage maintains 25000 VA continuous three-phase output off-grid. Overload capacity supports 30000 VA for 60 seconds to start inductive loads.
Pairs two battery inputs from 200 to 800 V
Two high-voltage Li-Ion inputs operate across a 200 to 800 V window. Smart fan cooling regulates the IP66 chassis from minus 35 to plus 60 C.
Technical data
Consolidating multi-orientation solar arrays and dual-tower storage into one high-power chassis.
3 MPPTs across 6 strings with dual independent 50 A battery ports.
Rather than deploying multiple smaller inverters with separate battery ports, the GW25K-ET accepts up to 37,500 W of solar input across 3 trackers (2 strings per MPPT). Its dual battery inputs allow commercial facilities to connect two independent high-voltage battery banks (up to 50 kW combined charge power), eliminating external DC combiner hardware and installation complexity.
- Continuous 3-Phase Power
- 25,000 VA
- 150% Solar DC Intake
- 37,500 Wp
- Dual 50 A Battery Ports
- 100 A
- High String Current
- 30 A / MPPT
Power & Phase
- Nominal output power (W)
- 25 kW
- Nominal apparent power output to utility grid (VA)
- 25 kVA
- Max. apparent power output to utility grid (VA)
- 27.5 kVA
- Max. apparent power from utility grid (VA)
- 25 kVA
- Power factor
- ~1 (adjustable from 0.8 leading to 0.8 lagging)
- Back-up nominal apparent power (VA)
- 25 kVA
- Max. output apparent power without grid (VA)
- 25000 (30000 @ 60 s)
- Max. output apparent power with grid (VA)
- 25 kVA
PV Input
- Maximum input power (W)
- 37.5 kW
- Maximum input voltage (V)
- 1000
- MPPT operating voltage range (V)
- 200 ~ 850
- Nominal input voltage (V)
- 620
- Maximum input current per MPPT (A)
- 30
- Maximum short circuit current per MPPT (A)
- 38
- Number of strings per MPPT
- 2 / 2 / 2
- MPPT efficiency
- 99.9%
Battery Interface
- Battery type
- Li-Ion
- Nominal battery voltage (V)
- 500
- Battery voltage range (V)
- 200 ~ 800
- Number of battery inputs
- 2
Efficiency & Protection
- Maximum efficiency
- 98.0%
- European efficiency
- 97.5%
- Maximum battery to AC efficiency
- 97.5%
- MPPT efficiency
- 99.9%
- Cooling method
- Smart fan cooling
- Ingress protection rating
- IP66
Physical & Comms
- Operating temperature range (C)
- -35 ~ +60
- Maximum operating altitude (m)
- 4000
- Communication with BMS
- RS485 / CAN
- Communication with meter
- RS485
- Communication with portal
- WiFi + LAN + Bluetooth
- Dimensions W x H x D (mm)
- 520 x 660 x 220
- Weight (kg)
- 54
Logistics
- Packaging (VPE)
- 1 per carton, 4 per pallet
Project fit
Where this model fits.
Scenarios that show which projects the GoodWe GW25K-ET belongs in, what to verify before quoting, and when another model is the better pick.
Complex Commercial Rooftops with 3 Distinct Pitches (30–38 kWp PV)
Commercial warehouses, logistics centers, or agricultural facilities with East, South, and West roof sections.
Grouping 3 orientations into 2 MPPTs forces parallel mismatch losses. The GW25K-ET’s 3 independent MPPTs (6 strings) allow dedicated tracking for each roof aspect without requiring expensive DC optimizers.
- BoundaryIf the roof has only 1 or 2 pitches and total array size is under 30 kWp, step down to the GW20K-ET to save capital cost.
- If the roof has only 1 or 2 pitches and total array size is under 30 kWp, step down to the GW20K-ET to save capital cost.
Facilities Requiring Dual-Tower High-Voltage Battery Storage (30–60 kWh Total)
Projects installing 30–60 kWh of storage to achieve high self-consumption and extended multi-hour emergency backup.
Allows connecting two separate battery stacks (e.g., two 20 kWh Lynx D towers) directly into dedicated inverter ports without purchasing external DC combiner switchgear.
- Confirm this model against the adjacent rating in the same family
Documents
GoodWe ET 15-30kW Series datasheet (EN) GoodWe ET Series 15-30kW Datasheet (EN) GoodWe Lynx-D Datasheet (EN)Product questions
Why are dual battery ports advantageous over a single battery port on a 25 kW inverter?
Eliminates external DC combiner boxes and avoids dangerously tall single stacks. Connecting large battery capacity (e.g., 40–50 kWh) to a single battery port requires either very tall single-column stacks (structural height and seismic risk) or an external parallel combiner box with DC fuses. The GW25K-ET’s dual battery ports (Port A and Port B) allow two independent, manageable floor stacks to plug directly into the inverter with dedicated internal fusing and 50 A charging per port.
Do the two battery towers connected to Port A and Port B have to be identical?
Yes. Both battery towers must use identical module counts and chemistry. Both ports share an internal DC bus architecture. For balanced operation and safe current distribution: * Both towers must have the same nominal voltage, identical module counts, and same cell chemistry. * *Do not mix*: A 3-module tower on Port A with a 5-module tower on Port B.
What is the maximum continuous AC export current on this model?
39.9 A max output current; 50 A or 63 A 3-pole industrial circuit breaker. * Nominal Output Current: Approx. 36.2 A per phase at 400 V three-phase. * Maximum Output Current: 39.9 A per phase (27,500 VA apparent power limit). * Breaker Recommendation: A 3-pole 50 A or 63 A industrial circuit breaker (MCB/MCCB) on the main AC distribution panel.
System components
Required components
GoodWe GM330 CT meter
Item number: DLK-GOODWE-GM330
Export limiting / self-consumption metering for grid-tied operation.
Recommended components
GoodWe LX D5.0-10 / Lynx D battery bank
Item number: DLK-GOODWE-LXD5010
Listed by GoodWe against the ET 15-30 kW range (ARM 28 / DSP 12 firmware or higher).
GoodWe GW61.4 / GW112.6-BAT-AC-G10 battery cabinet
Item number: DLK-GOODWE-GW614BATACG10
Listed by GoodWe against the ET 15-30 kW range, ARM 13 or higher required on the inverter.
Optional components
GoodWe GW60KWH-D-10 (60 kWh pack-based unit)
Item number: DLK-GOODWE-GW60KWHD10
This specific model of the Lynx C family is the one GoodWe clears for the ET 15-30 kW tier (the LX C101-10 to LX C156-10 cabinets are cleared for ET 40-50 and ETC/BTC instead).
GoodWe EzManager3000
Item number: DLK-GOODWE-EZMANAGER3000
Single-site home EMS for one hybrid inverter plus EV charger / heat pump / Shelly device control.
Approved pairings
GoodWe GW112.6-BAT-AC-G10Item number DLK-GOODWE-GW1126BATACG10GoodWe requires ARM 13 or higher on the ET 15-30 for the BAT series.
GoodWe GW61.4-BAT-AC-G10Item number DLK-GOODWE-GW614BATACG10GoodWe requires ARM 13 or higher on the ET 15-30 for the BAT series.
GoodWe GW60KWH-D-10Item number DLK-GOODWE-GW60KWHD10GW60KWH-D-10 only. GoodWe does not list LX C101-10 to LX C156-10 against the ET 15-30; those are listed against the ET 40-50 and the ETC / BTC.
GoodWe LX C101-10Item number DLK-GOODWE-LXC10110GW60KWH-D-10 only. GoodWe does not list LX C101-10 to LX C156-10 against the ET 15-30; those are listed against the ET 40-50 and the ETC / BTC.
GoodWe LX C120-10Item number DLK-GOODWE-LXC12010GW60KWH-D-10 only. GoodWe does not list LX C101-10 to LX C156-10 against the ET 15-30; those are listed against the ET 40-50 and the ETC / BTC.
GoodWe LX C138-10Item number DLK-GOODWE-LXC13810GW60KWH-D-10 only. GoodWe does not list LX C101-10 to LX C156-10 against the ET 15-30; those are listed against the ET 40-50 and the ETC / BTC.
GoodWe LX C156-10Item number DLK-GOODWE-LXC15610GW60KWH-D-10 only. GoodWe does not list LX C101-10 to LX C156-10 against the ET 15-30; those are listed against the ET 40-50 and the ETC / BTC.
GoodWe LX D5.0-10Item number DLK-GOODWE-LXD5010GoodWe requires ARM 28 and DSP 12 or higher on the ET for the Lynx D.
GoodWe Lynx D 10 kWh (2 x LX D5.0-10)Item number DLK-GOODWE-LYNXD10KWHGoodWe requires ARM 28 and DSP 12 or higher on the ET for the Lynx D.
GoodWe Lynx D 15 kWh (3 x LX D5.0-10)Item number DLK-GOODWE-LYNXD15KWHGoodWe requires ARM 28 and DSP 12 or higher on the ET for the Lynx D.
GoodWe Lynx D 20 kWh (4 x LX D5.0-10)Item number DLK-GOODWE-LYNXD20KWHGoodWe requires ARM 28 and DSP 12 or higher on the ET for the Lynx D.
GoodWe Lynx D 25 kWh (5 x LX D5.0-10)Item number DLK-GOODWE-LYNXD25KWHGoodWe requires ARM 28 and DSP 12 or higher on the ET for the Lynx D.
GoodWe Lynx Home F 13.10 kWh (PCU base + 4 x LX F3.3-H)Item number DLK-GOODWE-LXF131HGoodWe requires ARM 07 and DSP 06 or higher on the ET 15-30 kW for the Lynx Home F.
GoodWe Lynx Home F 16.38 kWh (PCU base + 5 x LX F3.3-H)Item number DLK-GOODWE-LXF164HGoodWe requires ARM 07 and DSP 06 or higher on the ET 15-30 kW for the Lynx Home F.
GoodWe LX F3.3-H (Lynx Home F battery module, 3.27 kWh)Item number DLK-GOODWE-LXF33HGoodWe requires ARM 07 and DSP 06 or higher on the ET 15-30 kW for the Lynx Home F.
GoodWe Lynx Home F 6.55 kWh (PCU base + 2 x LX F3.3-H)Item number DLK-GOODWE-LXF66HGoodWe requires ARM 07 and DSP 06 or higher on the ET 15-30 kW for the Lynx Home F.
GoodWe Lynx Home F 9.83 kWh (PCU base + 3 x LX F3.3-H)Item number DLK-GOODWE-LXF98HGoodWe requires ARM 07 and DSP 06 or higher on the ET 15-30 kW for the Lynx Home F.
GoodWe Lynx Home F PCU base (master BMS)Item number DLK-GOODWE-LXFPCUGoodWe requires ARM 07 and DSP 06 or higher on the ET 15-30 kW for the Lynx Home F.
Pylontech FH10050Item number DLK-PYLONTECH-FH10050Pylontech Ver. 2.43 lists a Force-H3 stack of 3 to 7 modules, and footnote e restricts this inverter to Force-H3 or Powercube-M1C. Our Force-H3 10.24 kWh is 2 modules and is below the minimum.
Pylontech Force-H3 10.24 kWh (2 x FH10050)Item number DLK-PYLONTECH-FORCEH31024KWHPylontech Ver. 2.43 lists a Force-H3 stack of 3 to 7 modules, and footnote e restricts this inverter to Force-H3 or Powercube-M1C. Our Force-H3 10.24 kWh is 2 modules and is below the minimum.
Pylontech Force-H3 15.36 kWh (3 x FH10050)Item number DLK-PYLONTECH-FORCEH31536KWHPylontech Ver. 2.43 lists a Force-H3 stack of 3 to 7 modules, and footnote e restricts this inverter to Force-H3 or Powercube-M1C. Our Force-H3 10.24 kWh is 2 modules and is below the minimum.
Pylontech Force-H3 20.48 kWh (4 x FH10050)Item number DLK-PYLONTECH-FORCEH32048KWHPylontech Ver. 2.43 lists a Force-H3 stack of 3 to 7 modules, and footnote e restricts this inverter to Force-H3 or Powercube-M1C. Our Force-H3 10.24 kWh is 2 modules and is below the minimum.
Pylontech Force-H3 25.6 kWh (5 x FH10050)Item number DLK-PYLONTECH-FORCEH3256KWHPylontech Ver. 2.43 lists a Force-H3 stack of 3 to 7 modules, and footnote e restricts this inverter to Force-H3 or Powercube-M1C. Our Force-H3 10.24 kWh is 2 modules and is below the minimum.
Pylontech Force-H3 30.72 kWh (6 x FH10050)Item number DLK-PYLONTECH-FORCEH33072KWHPylontech Ver. 2.43 lists a Force-H3 stack of 3 to 7 modules, and footnote e restricts this inverter to Force-H3 or Powercube-M1C. Our Force-H3 10.24 kWh is 2 modules and is below the minimum.
Pylontech Force-H3 35.84 kWh (7 x FH10050)Item number DLK-PYLONTECH-FORCEH33584KWHPylontech Ver. 2.43 lists a Force-H3 stack of 3 to 7 modules, and footnote e restricts this inverter to Force-H3 or Powercube-M1C. Our Force-H3 10.24 kWh is 2 modules and is below the minimum.
